Display Size 19"
Aspect Ratio 4:3
Brightness 1500Nits
Contrast 1000:1
Resolution 1280x1024
Connectivity 3G/HD/SD-SDI (with looped output), CVBS (with looped output), HDMI, VGA
Image Flip Horizontal & vertical
Input Voltage 12V DC
Aux. Output 12V DC, 3A max
Power Consumption 35W max
Power Supply 110-240V AC 50/60Hz input, 12V DC, 5A max. output
Hood Large (wide angle) composite hood with collapsible fabric lens seal
Rail Fixings 3/8"-16, with optional 1/4"-20 inserts
Camera Carriage Camera fixings: 2x 3/8"-16, 1/4"-20, Rod fixing: 2x 19mm rod fixings (studio standard 104mm pitch)
Camera base to lens centre height supported 50-140mm
Monitor Mounting VESA100 with additional 3-8"-16 camera support fixings
Counterweight mounting rods 2x 19mm dia.
Counterweight 5kg
Monitor Dimensions 420 x 356 x 57mm
Monitor Weight 4.4kg
System Dimensions 675 x 455 x 765mm
System Weight 11.9kg (excluding counterweight)
