Display Spec.
Model A737
Screen Size 7" IPS
Resolution 1920x1200 pixels
Pixel Pitch 0.07875 (H) x 0.07875 (W) (mm)
Aspect Ratio 16:10
Brightness 450cd/m²
Contrast Ratio 1200:1
Backlight LED
Viewing Angle 80°/80°(L/R) 80°/80°(U/D)
Input
1 X HDMI HDMI
1 X AV AV
1 X OSD Controller OSD Controller
Audio
Audio Stereo Headphone, Speaker
HDMI Support Format
480i/576i/480p/576p
1080i (60/59.94/50)
720p (60/59.94/50/30/29/25/24/23.98)
1080p (60/59.94/50/30/29.97/25/24/24sF/23.98/ 23.98sF)
4K UHD 3840×2160p (30/29.97/25/24/23.98Hz), 4096×2160p (24Hz)
General
Input Voltage DC7～24V
Power Consumption ≤8W
Working Temperature -20°C~55°C
Storage Temperature -30°C~65°C
Unit Size 180Lx140Hx17D (mm)
Unit Weight 490g/520g (with F970 Battery Plate)
Note: When you turn off the monitor, you need to press the power button, and you can't pull out the power cable directly.
Advanced Features
* Brightness Histogram
* Embedded Audio
* Peaking Focus Assist (Red, Green, Blue three colors optional highlight over parts of the image in focus)
* False Colors
* Zebra Exposure (1-100IRE adjustable)
* Check Field (Red, Green, Blue, Mono)
* Camera Mode
* Anamorphic Mode (1.3x, 2.0x, 2.0x mag)
* Image Flip (H, V, H/V)
* Image Freeze
* Center Marker
* Screen Marker (80%,85%,90%,93%,96%, 2.35:1)
* Ratio marker (4:3,13:9,14:9,15:9,16:9,1.85:1,2.35:1)
* Color Temperature Adjustment
* Nine Grid (Zoom one of the images to realize the full screen) (Nonsupport in 4K input)
* Zoom (4X, 9X, 16X) (Nonsupport in 4K input)
* Aspect Ratio (Nonsupport in 4K input)
* Pixel to Pixel (Nonsupport in 4K input)
* Zoom All (Nonsupport in 4K input)
* U/D Zoom (Nonsupport in 4K input)
* L/R Zoom (Nonsupport in 4K input)
