INPUT1 / INPUT2
Input Terminal
XLR 3-pin (female)
Standard Input Level
LINE: 0 dBu
MIC, +48V: -40 dBu
(0 dBu=0.775 Vrms)
Standard Recording Level
-12 dBFS (at the standard input)
Frequency Characteristic
20Hz to 40kHz, +1/-1 dB (during Fs=96kHz, during LINE)
Phantom Power Source 48V
INPUT3
Input Terminal
φ3.5mm stereo mini jack
Standard Input Level
LINE: -10 dBV
MIC, MIC (plug-in power): -40 dBV
(0 dBV=1 Vrms)
Standard Recording Level
-12 dBFS (at the standard input)
Frequency Characteristic
20Hz to 40kHz, +1/-1 dB (during Fs=96kHz, during LINE)
Plug-in Power 2.5V
Sampling Frequency Bit Length / Number of Recording Channels
Linear Recording
48kHz/24-bit/2ch, 96kHz/24-bit/2ch
(Select one of INPUT1, INPUT1+2, or INPUT3)
48kHz/24-bit/4ch
Float Recording
48kHz/32-bit/2ch, 96kHz/32-bit/2ch
(Select one of INPUT1, INPUT1+2, or INPUT3)
48kHz/32-bit/4ch
Dimensions (W x H x D)
Approx. 61.2 x 60.9 x 92 mm / 2.41 x 2.40 x 3.63 inch (without microphone holder)
Approx. 94.6 x 106.2 x 92 mm / 3.73 x 4.19 x 3.63 inch (with microphone holder)
(excluding the projecting parts)
Weight
Approx. 158 g / 0.35 lb (without microphone holder)
Approx. 192 g / 0.43 lb (with microphone holder)
Operating Temperature
-10℃ to 40℃ (14℉ to 104℉)
Operating Humidity
10 - 80 %RH
