Dimensions
139.7×42.2×33.5 mm (L×W×H)
Weight
179 g
Number of Microphones
3
Touchscreen
Size: 2.0 inches
Resolution: 314×556
Brightness: 700 nits
Supported SD Cards
microSD (up to 512 GB)
Recommended microSD Cards
Recommended models:
SanDisk Extreme Pro 32GB V30 A1 UHS-I Speed Grade 3
Kingston Canvas Go!Plus 64GB UHS-I Speed Grade 3
Kingston Canvas Go!Plus 128GB UHS-I Speed Grade 3
Kingston Canvas React Plus 64GB UHS-II Speed Grade 3
Kingston Canvas React Plus 128GB UHS-II Speed Grade 3
Kingston Canvas React Plus 256GB UHS-II Speed Grade 3
Lexar Pro 256GB SDXC UHS-I V30 R160/W120 (1066x)
Lexar Pro 512GB SDXC UHS-I V30 R160/W120 (1066x)
Gimbal
Controllable Range
Pan: -235° to 58°
Tilt: -120° to 70°
Roll: -45° to 45°
Mechanical Range
Pan: -240° to 63°
Tilt: -180° to 98°
Roll: -220° to 63°
Max Controllable Speed
180.0°/s
Angular Vibration Range
±0.005°
Camera
Sensor
1-inch CMOS
Lens
Format Equivalent: 20 mm
Aperture: f/2.0
Focus Range: 0.2 m to ∞
ISO Range
Photo: 50-6400
Video: 50-6400
Low-Light Video: 50-16000
Slow Motion: 50-6400
Electronic Shutter Speed
Photo: 1/8000-1 s
Video: 1/8000 s to the limit of frames per second
Max Image Size
16:9, 3840×2160
1:1, 3072×3072
Zoom
Digital Zoom
Photo: 3840×2160, 2x
Video: 1080p, 4x; 2.7K, 3x; 4K, 2x
UVC & Livestream: 1080p, 4x
Slow Motion/Timelapse: Not available
Still Photography Modes
Single Shot: Approx. 9.4 MP
Countdown: Off/3/5/7 s
Panorama: 180°, 3×3
Normal Video
4K (16:9): 3840×2160@24/25/30/48/50/60fps
2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
3K (1:1): 3072×3072@24/25/30/48/50/60fps
2160p (1:1): 2160×2160@24/25/30/48/50/60fps
1080p (1:1): 1080×1080@24/25/30/48/50/60fps
3K (9:16): 1728×3072@24/25/30/48/50/60fps
2.7K (9:16): 1512×2688@24/25/30/48/50/60fps
1080p (9:16): 1080×1920@24/25/30/48/50/60fps
Slow Motion
4K (16:9): 3840×2160@120fps
2.7K: 2688×1512@120fps
1080p: 1920×1080@120/240fps
Hyperlapse
4K/2.7K/1080p@25/30fps: Auto/×2/×5/×10/×15/×30
Timelapse
4K/2.7K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s
Duration: 5/10/20/30 mins, 1/2/3/5/∞ hours
Motionlapse
4K/2.7K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s
Duration: 5/10/20/30 mins, 1/2/3/5 hours
Supports setting four positions
Low-Light Video
4K (16:9): 3840×2160@24/25/30fps
1080p: 1920×1080@24/25/30fps
Max Video Bitrate
130 Mbps
Supported File System
exFAT
Photo Format
JPEG/JPEG+DNG
Video Format
MP4 (H.264/HEVC)
Built-in Storage Capacity
The camera does not have built-in storage,
but storage capacity can be expanded by inserting a microSD card.
Audio Output
48 kHz 16-bit; AAC
Battery
Type
LiPo
Capacity
1300 mAh
Energy
10.01 Wh
Voltage
7.70 V
Operating Temperature
0° to 40° C (32° to 104° F)
Charging Temperature
5° to 45° C (41° to 113° F)
Operating Time
166 mins
Tested at room temperature (25° C/77° F)
and 1080p/24fps (16:9), with Wi-Fi off and screen off.
This data is for reference only.
Charging Time
16 mins to 80%; 32 mins to 100%
Tested in a laboratory environment with
the DJI 65W PD charger (sold separately).
Connection
Wi-Fi Operating Frequency
2.400-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz
Wi-Fi Protocol
802.11 a/b/g/n/ac
Wi-Fi Transmitter Power (EIRP)
2.4 GHz:
< 23 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)5.1 GHz:
< 23 dBm (FCC/SRRC)
< 20 dBm (CE)5.8 GHz:
< 23 dBm (FCC/SRRC)
< 14 dBm (CE)
Bluetooth Operating Frequency
2.400-2.4835 GHz
Bluetooth Transmitter Power (EIRP)
< 14 dBm
Bluetooth Protocol
BLE 5.2, BR/EDR
