Power
DC 7.28 V (when the battery is used)
DC 12 V (when the AC adaptor is used)
Power consumption
12.2 W (when the LCD monitor is used)
Operating temperature
0 °C to 40 °C
Operating humidity
10 % to 80 % (no condensation)
Weight
Body: Approx. 1.9 kg (4.19 lb)
(body only, excluding lens hood, battery, and accessories)
Shooting: Approx. 2.3 kg (5.07 lb)
(including lens hood, battery, and eye cup)
Dimensions
169 mm (W) x 195 mm (H) x 340 mm (D)
(6-21/32 inches x 7-11/16 inches x 13-3/8 inches)
(excluding protrusion and eye cup)
169 mm (W) x 195 mm (H) x 382 mm(D)
(6-21/32 inches x 7-11/16 inches x 15-1/32 inches)
(including eye cup, excluding protrusion)
Pickup Devices
1.0-type MOS solid state image sensor
Effective Pixels
17.78 megapixel: FHD 59.94p/29.97p/23.98p
8.59 megapixel: UHD 29.97p/23.98p
LENS
Optical image stabilizer lens,
optical 15x motorized zoom
F2.8 to F4.5 (f=8.8 mm to 132 mm)
35 mm equivalent:
f=24.5 mm to 367.5 mm: FHD 59.94p/29.97p/23.98p
f=35.4 mm to 531.0 mm: UHD 29.97p/23.98p
Filter Diameter: 67 mm
ND Filter: 4 Positions (OFF, 1/4, 1/16, 1/64)
Shortest Shooting Distance (M.O.D.):
Approx. 1.0 m from the front lens
Gain setting
L/M/H selector switch (toggle switch)
Standard mode: 0 dB to 30 dB (Adjustable in 1 dB steps)
(Automatic setting can be assigned to L/M/H)
Extended ON: -3 dB to 30 dB (Adjustable in 1 dB steps)
(Automatic setting can be assigned to L/M/H)
33 dB and 36 dB switched
(when assigning [S.GAIN] to the USER button)
Color Temperature Setting
ATW, ATW LOCK, Ach, Bch,
preset 3200 K/preset 5600 K/VAR (2000 K to 15000 K)
Shutter Speed
60i/60p mode: 1/60 sec., 1/100 sec., 1/120 sec.,
1/180 sec., 1/250 sec., 1/350 sec., 1/500 sec.,
1/750 sec., 1/1000 sec., 1/1500 sec., 1/2000 sec.,
1/3000 sec., 1/4000 sec., 1/8000 sec.
30p mode: 1/30 sec., 1/50 sec., 1/60 sec., 1/100 sec.,
1/120 sec., 1/180 sec., 1/250 sec., 1/350 sec.,
1/500 sec., 1/750 sec., 1/1000 sec., 1/1500 sec.,
1/2000 sec., 1/3000 sec., 1/4000 sec., 1/8000 sec.
24p mode: 1/24 sec., 1/48 sec., 1/50 sec., 1/60 sec.,
1/100 sec., 1/120 sec., 1/180 sec., 1/250 sec.,
1/350 sec., 1/500 sec., 1/750 sec., 1/1000 sec.,
1/1500 sec., 1/2000 sec., 1/3000 sec., 1/4000 sec.,
1/8000 sec.
Shutter Speed (Slow Shutter)
60i/60p mode: 1/2 sec., 1/4 sec., 1/8 sec., 1/15 sec., 1/30 sec.
30p mode: 1/2 sec., 1/4 sec., 1/8 sec., 1/15 sec.
24p mode: 1/2 sec., 1/3 sec., 1/6 sec., 1/12 sec.
VFR Recording Frame Rate
30p mode: 2, 15, 26, 28, 30, 32, 34, 45, 60 (fps)
24p mode: 2, 12, 20, 22, 24, 26, 28, 36, 48, 60 (fps)
Minimum Subject Illumination
1.3 lx
(F2.8, Super Gain 36dB, Manual slow shutter 1/30s)
DIGITAL ZOOM
2x/5x/10x,
i.Zoom: max. 25x (optical zoom + digital zoom)
Recording Media*1
SDHC memory card (4 GB to 32 GB),
SDXC memory card (48 GB to 128 GB)
UHS-I supported
Recording slot
Slot x 2
System format
59.94 Hz
Recording Format
MOV, MP4, AVCHD
Recording Mode
Please see page 1 for the Recording Format table.
Recording Time
Please see below for the Recording Time table.
2 Slot Functions
Relay, Simultaneous
Still Picture Recording Mode
JPEG (DCF/Exif2.2)
Still picture recording
Motion Picture Playback:
8.3 M: 3840 x 2160 (16:9),
2.1 M: 1920 x 1080 (16:9),
0.9 M: 1280 x 720 (16:9)
Video Signal for External Output
8 bit 4:2:2
Recording video signal
8 bit 4:2:0
Video Compression Format
MPEG-4 AVC/H.264 High Profile (MOV/MP4/AVCHD)
Sampling Frequency
48 kHz/16 bit 2 ch
Audio Signal Format
LPCM (MOV/MP4), Dolby Digital (AVCHD)
Headroom
12 dB
Built-in microphone
Stereo microphone
XLR Input
XLR (3-pin) x 2 (INPUT1, INPUT2)
high impedance, LINE/MIC/MIC+48V (switchable SW)
LINE: +4 dBu/0 dBu (switchable menu)
MIC: -40 dBu/-50 dBu/-60 dBu (switchable menu)
HDMI (Audio Output)
2 ch (LPCM)
Audio OUT
AUDIO OUT: 2X AUDIO OUT
Headphone
3.5 mm diameter stereo mini jack
Speaker
20 mm diameter, round
Camera Remote
2.5 mm diameter super mini jack (ZOOM, S/S)
3.5 mm diameter mini jack x1 (FOCUS, IRIS)
USB 3.0 (Host)
Standard-A connector,9-pin, external media device connection*2, bus power supported
DC IN 12V
DC 12 V (11.4 V to 12.6 V) EIAJ Type4
LCD monitor
3.5-type LCD monitor, Approx. 1,150,000 dots
View Finder
0.24-type EVF, Approx. 1,560,000 dots equivalent
