Power
DC 7.28 V (battery operation)
DC 12 V (AC adapter operation)
Power consumption
19 W (with LCD/HDMI/SDI ON)
Operating temperature
0 °C to 40 °C
Operating humidity
10% to 85% (relative humidity)
Storage Temperature
-20 °C to 60 °C
Weight
Body: Approx. 1.2 kg (2.65 lb)
(excluding accessories)
Shooting: Approx. 2.05 kg (4.52 lb)
(with accessories)
Dimensions
135 mm (W) x 133 mm (H) x 170 mm (D)
(excluding protrusions and accessories)
(5-5/16 inches x 5-1/4 inches x 6-11/16 inches)
Number of Pixels
Total pixels:
Approx. 20.49 megapixels, 6340 (H) x 3232 (V)
Effective pixels:
Approx. 17.25 megapixels, 5720 (H) x 3016 (V)
Sensor Area and Max Frame Rate
S35: 4K/UHD 60 fps/50 fps
2K/HD 120 fps/100 fps
4/3": 2K/HD 240 fps/200 fps
Latitude
14 stop
Log
V-Log
Gamma
eV-Look Gamma (2 types)
Video Gamma
Hybrid Log Gamma (HLG)
Gamut
V-Gamut (V-Log)
EI Settings
[ISO] mode: NATIVE ISO: 800, 2500
800 Base: 200 to 2000
2500 Base: 1000 to 25600
[dB] mode: (Normal) -12 dB to 8 dB
(High) -8 dB to 20 dB
Shutter Speed
[deg] mode: 1.0 deg to 358 deg (0.5 deg step)
12 presets
[sec] mode: 1/24.1 sec to 1/8000 sec (23.98p)
12 presets
Color Temp
ATW, AWB, 2000 K to 15000 K ±10.0 GMg
12 presets
Lens Mount
EF mount
Image Stabilization
Electric Image Stabilization (EIS)
Auto Focus
One push auto focus
ND filter
CLEAR, 0.6ND, 1.2ND, 1.8ND, Electrical driven
IR Cut Filter
USER assignable IR shooting (filter ON/OFF)
Recording Media
SDHC memory card (4 GB to 32 GB)
SDXC memory card (32 GB to 128 GB)
UHS-Ⅰ/UHS-Ⅱ UHS Speed Class3 is supported,
Video Speed Class V90 is supported
Recording slot
SD memory card slot x 2
Recording Resolution
4096 x 2160 (4K), 3840 x 2160 (UHD),
2048 x 1080 (2K), 1920 x 1080 (FHD),
1280 x 720 (HD)
Recording System Frequency
59.94p, 50p, 29.97p, 25p, 24p, 23.98p
59.94i, 50i (AVCHD only)
2slot Functions
Simul Rec, Relay Rec, Loop Rec*1,
Background Rec*1
Other Rec Functions
Pre Rec, Interval Rec*1, One Shot Rec*1
Quantizing
MOV: 4:2:2 10 bit/4:2:0 8 bit
AVCHD: 4:2:0 8 bit
Video Compression Format
H.264/MPEG-4 AVC High Profile
Recording Audio Format
MOV: 48 kHz/24 bit, 2 CH, Linear PCM
AVCHD: 48 kHz/16 bit, 2 CH, Dolby Audio™
Headroom
18 dB/20 dB (menu switchable)
Video Output | SDI OUT
BNC x 1, SDI REC REMOTE is supported
0.8 V [p-p], 75 Ω, 4K (6G), HD (3G/1.5G)
Output format (4:2:2 10 bit):
・4096 x 2160: 29.97p, 25p, 24p, 23.98p
・3840 x 2160: 29.97p, 25p, 24p, 23.98p
・1920 x 1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 29.97PsF, 25p, 25PsF, 24p, 24PsF, 23.98p, 23.98PsF
・1280 x 720p: 59.94p, 50p
RAW* output format (10 bit):
・5760 x 3072: 29.97p, 25p, 24p, 23.98p
・4096 x 2160: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p
Video Output | HDMI
HDMI x 1, TypeA, HDMI REC REMOTE is supported,
Viera Link is NOT supported
Output format (4:2:2 10 bit):
・4096 x 2160: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p
・3840 x 2160: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p
・1920 x 1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 25p, 24p, 23.98p
・1280 x 720: 59.94p, 50p
・720 x 480: 59.94p
・720 x 576: 50p
Output format (4:2:0 8 bit):
・4096 x 2160: 59.94p, 50p
・3840 x 2160: 59.94p, 50p
Internal Mic
Stereo microphone
INPUT1/2
XLR (3-pin) x 2 (INPUT1/2), input high impedance,
LINE/MIC/MIC +48 V (menu switchable)
MIC: -40 dBu/-50 dBu/-60 dBu (menu switchable)
LINE: +4 dBu/0 dBu (menu switchable)
Audio Input/Output | SDI OUT
Linear PCM 2 CH
Audio Input/Output | HDMI
Linear PCM 2 CH
Phones
3.5 mm stereo mini jack x 1
Speaker
20 mm diameter, round x 1
TC IN/OUT
BNC x1 for IN/OUT (menu switchable)
IN: 1.0 V [p-p] to 4.0 V [p-p], 10 kΩ
OUT: 2.0 V [p-p] ±0.5 V [p-p], low impedance
LCD
40-pin (Dedicated)
REMOTE
2.5 mm Super Mini Jack
USB 2.0 (HOST)
Type-A, 4-pin for Wireless Module (AJ-WM50)
EF Mounting Contact
8-pin
DC IN 12V
DC 12 V (10.5 V to 13.5 V) EIAJ type 4
Size
3.5-type LCD monitor (approx. 1,150,000 dots)
Touch panel
(MENU control, Shooting assist functions)
LCD Monitor | Switches
MIRROR (OFF, B/T, ROTATE)
Mounting Mechanism
One touch rotatable/Detachable
Hand Grip | Switches
REC, MENU/IRIS dial, User switch x 2
