INPUTS
MIC/LINE (mono) Connectors 2 XLR/TRS combo jacks (XLR: 2 HOT, TRS: TIP HOT)
Input gain Adjustment unnecessary (dual A/D converter circuits used)
Input impedance MIC: 2.7 kΩ or more
LINE: 1 kΩ or more
Maximum input level MIC: +4 dBu
LINE: +24 dBu
Phantom power +48 V
Channel total 10 mA or less
Equivalent input noise MIC: –122 dBu or less (IHF-A) at 150Ω input
LINE: –100 dBu or less (IHF-A) at 600Ω input
MIC/LINE IN jack Connector Stereo mini jack
Input impedance 2 kΩ
Plug-in power 2.5 V
OUTPUTS
PHONE / LINE OUT jack Connector Stereo mini jack
Maximum output level 20 mW + 20 mW (when 32 Ω load)
Output impedance 10 Ω or less
Built-in speaker Type 20 mm × 30 mm elliptical dynamic speaker
Effective maximum output 250mW
RECORDER
Recording format WAV
44.1, 48 or 96 kHz / 32-bit float
Stereo / Mono
BWF and iXML formats supported
Recording media 4 – 32GB cards compatible with the microSDHC specification
64GB – 1TB cards compatible with the microSDXC specification
DISPLAY
OLED 128 x 64
USB
Connector USB Type-C
• Use a USB cable that supports data transfer.
Audio interface USB Audio Class 1.0
Input and output channels 2 in / 2 out (Stereo)
Sampling frequencies 44.1, 48 kHz
Bit depths 16-bit, 32-bit float
File transfer USB 2.0 High Speed
POWER
2 AA batteries Alkaline, Lithium, or Rechargeable NiMH
AC adapter ZOOM AD-17: DC 5 V/1 A
• USB bus power is supported.
ESTIMATED CONTINUOUS OPERATION TIME USING BATTERIES (Phantom Power OFF)
Alkaline batteries About 12 hours
NiMH batteries (1900 mAh) About 11 hours
Lithium batteries About 19 hours
INPUT 1 and 2 recording at 48 kHz/32-bit float, phantom power off, no headphones, Power Save Time set to 1 minute
These values are approximate.
Continuous battery operation times were determined using in-house testing methods.
They will vary greatly according to use conditions.
ESTIMATED CONTINUOUS OPERATION TIME USING BATTERIES (Phantom Power ON)
Alkaline batteries About 4 hours
NiMH batteries (1900 mAh) About 3 hours
Lithium batteries About 9 hours
INPUT 1 and 2 recording at 48 kHz/32-bit float, phantom power on (INPUT 1), no headphones, Power Save Time set to 1 minute
These values are approximate.
Continuous battery operation times were determined using in-house testing methods.
They will vary greatly according to use conditions.
Power consumption 2.5 W maximum
Dimensions 62.1 mm (W) × 107 mm (D) × 39.3 mm (H)
Weight (including batteries) 164 g
Note: 0 dBu = 0.775 Vrms
