Mass
Approx. 830 g (body only)
Approx. 1 lb 13.2 oz (body only)
Approx. 2.2 kg (with SELP18105G and lens hood [optional], battery pack BP-U30, large eyecup, LCD panel, handle, grip w/o grip belt)
Approx. 4 lb 14.5 oz (with SELP18105G and lens hood [optional], battery pack BP-U30, large eyecup, LCD panel, handle, grip w/o grip belt)
Dimensions (W x H x D)
*1Approx. 111.3 x 128.7 x 172.4 mm (body only including the projecting parts)
Approx. 185.2 x 218.3 x 369.5 mm (with SELP18105G and lens hood [optional], large eyecup, LCD panel, handle, grip w/o grip belt and including the projecting parts)
Approx. 4 1/2 x 5 1/8 x 6 7/8 inches (body only including the projecting parts)
Approx. 7 3/8 x 8 5/8 x 14 5/8 inches (with SELP18105G and lens hood [optional], large eyecup, LCD panel, handle, grip w/o grip belt and including the projecting parts)
Power Requirements
DC 14.4 V (battery pack)
DC 12.0 V (AC adaptor)
Power Consumption
Approx. 11.8 W [60i]
Approx. 11.5 W [50i]
(while recording with LCD Off, EVF On when the external device connector is not used.)
Approx. 12.6 W [60i]
Approx. 12.3 W [50i]
(while recording with LCD On, EVF On when the external device connector is used.)
Operating Temperature
0°C to 40°C
Storage Temperature-
20°C to +60°C
Battery Operating Time
With battery pack BP-U90: approx. 6 hours, 40 minutes [60i] approx. 6 hours, 45 minutes [50i]
(While recording with LCD On, EVF Off when the external device connector is not used.)
With battery pack BP-U60: approx. 4 hours, 15 minutes [60i]
approx. 4 hours, 20 minutes [50i]
(While recording with LCD On, EVF Off when the external device connector is not used.)
With battery pack BP-U30: approx. 2 hours, 10 minutes [60i]
approx. 2 hours, 10 minutes [50i]
(While recording with LCD On, EVF Off when the external device connector is not used.)
Recording Format (Video)
XAVC QFHD: MPEG-4 AVC/H.264
4:2:0 Long profile
XAVC HD: MPEG-4 AVC/H.264
4:2:2 Long profile
AVCHD: MPEG-4 AVC/H.264
AVCHD 2.0 format compatible
Recording Format (Audio)
XAVC: Linear PCM 2ch, 24 bit, 48 kHz
AVCHD: Linear PCM 2ch, 16 bit, 48 kHz/Dolby Digital 2ch, 16 bit, 48 kHz
Recording Frame Rate
XAVC QFHD (3840 x 2160) @29.97p, 25p, 23.98p,
100 Mbps/60 Mbps
XAVC HD (1920 x 1080) @59.94p, 50p,
50 Mbps/35 Mbps
XAVC HD (1920 x 1080)@59.94i, 50i,
50 Mbps/35 Mbps/25 Mbps
XAVC HD (1920 x 1080)@29.97p, 25p, 23.98p,
50 Mbps/35 Mbps
XAVC HD (1280 x 720)@59.94p, 50p,
50 Mbps
AVCHD (1920 x 1080)@59.94p, 50p,
PS mode (28 Mbps)
AVCHD (1920 x 1080)
@59.94i/50i/29.97p/25p/23.98p,
FX mode (24 Mbps)
FH mode (17 Mbps)
AVCHD (1280 x 720)@59.94p, 50p,
FX mode (24 Mbps)
FH mode (17 Mbps)
HQ mode (9 Mbps)
Recording/Playback Time
<XAVC Long>
XAVC-L QFHD 100 mode
Approx. 65 min with 64-GB memory card
XAVC-L QFHD 60 mode
Approx. 100 min with 64-GB memory card
XAVC-L HD 50 mode
Approx. 120 min with 64-GB memory card
XAVC-L HD 35 mode
Approx. 170 min with 64-GB memory card
XAVC-L HD 25 mode
Approx. 220 min with 64-GB memory card
Recording/Playback Time — Continued
<AVCHD>
AVCHD@LPCM 2ch PS Mode
Approx. 290 min with 64-GB memory card
Approx. 145 min with 32-GB memory card
AVCHD@LPCM 2ch FX Mode
Approx. 340 min with 64-GB memory card
Approx. 170 min with 32-GB memory card
AVCHD@LPCM 2ch FH Mode
Approx. 450 min with 64-GB memory card
Approx. 225 min with 32-GB memory card
AVCHD@LPCM 2ch HQ Mode
Approx. 590 min with 64-GB memory card
Approx. 290 min with 32-GB memory card
Lens Mount
E-mount
Focal Length
5.8x (optical), servo
(SELP18105G)
f = 18–105mm
equivalent to f = 30.6–178.5 mm on 35-mm lens (16:9)
(SELP18105G)
Iris
F4
(SELP18105G)
Focus
AF/MF selectable,
Wide: 450 mm to ∞
Tele: 950 mm to ∞
(SELP18105G)
Image Stabilizer
ON/OFF selectable, shift lens
(SELP18105G)
Filter Diameter
2.83 in
(SELP18105G)
Imaging Device (Type)
"Exmor" Super35 CMOS Sensor
Effective Picture Elements
3840 (H) x 2160 (V) (16:9)
4096 (H) x 2160 (V) (17:9, at RAW output)
Built-in Optical Filters
ND filters
OFF: CLEAR
1: 1/4ND
2: 1/16ND
3: 1/64ND
Linear variable ND (1/4ND to 1/128ND)
ISO Sensitivity
S-Log2/Log3 Gamma ISO2000
Minimum Illumination
0.16 Lux [60i] (IRIS F1.4, GAIN Auto, Shutter Speed 1/24)
0.18 Lux [50i] (IRIS F1.4, GAIN Auto, Shutter Speed 1/25)
Horizontal Rezolution
1000 TV lines or more (1920 x 1080i mode)
Shutter Speed
1/8 to 1/10000 sec. (60i)
1/6 to 1/10000 sec. (50i/24p)
Slow and Quick Motion Function
[30p]: 2160p: Frame rate selectable
1.2.4.8.15.30 fps
[25p]: 2160p: Frame rate selectable
1.2.3.6.12.25 fps
[60i]: 1080p: Frame rate selectable
1, 2, 4, 8, 15, 30, 60, 120 fps
[50i]: 1080p: Frame rate selectable
1, 2, 3, 6, 12, 25, 50, 100 fps
Super Slow Motion Function
[60i] Frame rate selectable
120, 240, 480, 960 fps
[50i] Frame rate selectable
100, 200, 400, 800 fps
White Balance
Preset (3200K), Memory A,
Memory B/ATW
Gain
0,3,6,9,12,15,18,24,27,30dB,AGC
Gamma Curve
Selectable
Audio Input
XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable
Video Output
Integrated into Multi/Micro USB jack
Composite
1.0 V p-p, 75 Ω
Audio Output
Integrated into Multi/Micro USB jack
SDI Output
BNC type (x1), SD/HD/3G(Level-B) selectable
SMTPE 259M/292M/424M/425M standards
USB
Multi/Micro USB jack
Headphone Output
Stereo mini jack
Speaker Output
Monaural
DC Input
DC jack
Remote
Stereo mini-mini jack (Φ2.5 mm)
HDMI Output
HDMI connector (Type A)
Viewfinder
1.0 cm (0.39 type) OLED
Approx. 1.44 M dots
LCD
8.8cm (3.5 type) Approx. 1.56M dots
Built-in Microphone
Omni-directional stereo electret condenser microphone
Type
MS/SD(1),SD(1)
Supported Format
IEEE 802.11 b/g/n
Frequency Band
2.4 GHz bandwidth
Security
WEP/WPA-PSK/WPA2-PSK
NFC
NFC Forum Type 3 Tag compliant
