Item Type
1 x COB LED Light Panel
Included Light Modifier
1 x Dome
Included Storage Case
None
Photometrics
5600K:
1543 fc / 16,602 Lux at 3.3' / 1 m
171 fc / 1839 Lux at 9.8' / 3 m
43 fc / 462 Lux at 19.6' / 6 m
15 fc / 161 Lux at 32.8' / 10 m
*Standardized Measurement Supplied by the Manufacturer
3200K:
1458 fc / 15,688 Lux at 3.3' / 1 m
162 fc / 1743 Lux at 9.8' / 3 m
40 fc / 430 Lux at 19.6' / 6 m
15 fc / 161 Lux at 32.8' / 10 m
*Standardized Measurement Supplied by the Manufacturer
5600K:
1263 fc / 13,589 Lux at 3.3' / 1 m (with Filter)
140 fc / 1506 Lux at 9.8' / 3 m (with Filter)
35 fc / 376 Lux at 19.6' / 6 m (with Filter)
13 fc / 139 Lux at 32.8' / 10 m (with Filter)
*Standardized Measurement Supplied by the Manufacturer
3200K:
1198 fc / 12,890 Lux at 3.3' / 1 m (with Filter)
133 fc / 1431 Lux at 9.8' / 3 m (with Filter)
33 fc / 355 Lux at 19.6' / 6 m (with Filter)
12 fc / 129 Lux at 32.8' / 10 m (with Filter)
*Standardized Measurement Supplied by the Manufacturer
Show More
Color Temperature
1500 to 20,000K
Color Modes
RGB, Daylight, Tungsten
Color Accuracy Standard
CRI 99
TLCI 93
Dimming
Yes, Built-In Dimmer
0 to 100% (Continuous)
Beam Angle
120° Unmodified
106° with Included Diffuser
Front Accessory Mount
Proprietary
Wireless Remote Control Type
Art-Net
Bluetooth 5.0
Wireless CRMX
Wireless DMX (G3 / G4 / G4S / G5)
Show More
Power Source
AC Power (Cable Included) *Requires Power Supply/Controller (Included)
Battery (Not Included)
AC Input Power
100 to 240 VAC, 50 / 60 Hz
DC Input Power
48 VDC
Power Consumption
800 W
Fixture Mounting
Support Mount
1 x 1-1/8" Stud
Light Fixture
Item Type
1 x COB LED Light Panel
Included Light Modifier
1 x Dome
Included Storage Case
None
Lumens
51,809 (at 5600K)
48,253 (at 3200K)
Photometrics
5600K:
1543 fc / 16,602 Lux at 3.3' / 1 m
171 fc / 1839 Lux at 9.8' / 3 m
43 fc / 462 Lux at 19.6' / 6 m
15 fc / 161 Lux at 32.8' / 10 m
*Standardized Measurement Supplied by the Manufacturer
3200K:
1458 fc / 15,688 Lux at 3.3' / 1 m
162 fc / 1743 Lux at 9.8' / 3 m
40 fc / 430 Lux at 19.6' / 6 m
15 fc / 161 Lux at 32.8' / 10 m
*Standardized Measurement Supplied by the Manufacturer
5600K:
1263 fc / 13,589 Lux at 3.3' / 1 m (with Filter)
140 fc / 1506 Lux at 9.8' / 3 m (with Filter)
35 fc / 376 Lux at 19.6' / 6 m (with Filter)
13 fc / 139 Lux at 32.8' / 10 m (with Filter)
*Standardized Measurement Supplied by the Manufacturer
3200K:
1198 fc / 12,890 Lux at 3.3' / 1 m (with Filter)
133 fc / 1431 Lux at 9.8' / 3 m (with Filter)
33 fc / 355 Lux at 19.6' / 6 m (with Filter)
12 fc / 129 Lux at 32.8' / 10 m (with Filter)
*Standardized Measurement Supplied by the Manufacturer
Color Temperature
1500 to 20,000K
Color Modes
RGB, Daylight, Tungsten
Color Accuracy Standard
CRI 99
TLCI 93
Cooling System
Fan/Passive Combo
Dimming
Yes, Built-In Dimmer
0 to 100% (Continuous)
Expected Lamp Life
50,000 Hours
Beam Angle
120° Unmodified
106° with Included Diffuser
Built-In Flash
No
Umbrella Mount
No
Front Accessory Mount
Proprietary
Connectivity
Wireless Remote Control Type
Art-Net
Bluetooth 5.0
Wireless CRMX
Wireless DMX (G3 / G4 / G4S / G5)
Mobile App Compatible
Yes: Android & iOS
App Name: ARRI LiCo
*As of September, 2023: Check with manufacturer for the most up-to-date compatibility
Power & I/O
Power Source
AC Power (Cable Included) *Requires Power Supply/Controller (Included)
Battery (Not Included)
Inputs/Outputs
Light Fixture
1 x XLR 5-Pin DMX Input
1 x XLR 5-Pin DMX Output
2 x etherCON/RJ45 DMX/Network Input/Output
1 x USB-C Remote/Service Input
1 x XLR 3-Pin Battery Input (48 VDC)
To Light Fixture: 1 x powerCON TRUE1 TOP Power Input
1 x Unspecified Remote Input
AC Input Power
100 to 240 VAC, 50 / 60 Hz
DC Input Power
48 VDC
Included Adapter / Cable
1 x Edison Plug to powerCON TRUE1 TOP Cable (9.8' / 3 m)
Inline Switch
No
Power Pass-Thru
Yes
Power Consumption
800 W
Mounting
Yoke Type
Manually-Operated Yoke
Fixture Mounting
Support Mount
1 x 1-1/8" Stud
Environmental
Environmental Protection
Advertised as Dust Resistant/Moisture Resistant/Weather Resistant
*Manufacturer Testing: IP66
Operating Temperature
104°F / 40°C
General
Display
Yes
Certifications
CE, CB, ENEC, cNRTLus, FCC, UKCA, ICES, PSE, KC
Dimensions
29.1 x 13.3 x 6.1" / 73.8 x 33.9 x 15.4 cm (Fixture without Yoke)
Weight
33.1 lb / 15 kg (Fixture)
39.7 lb / 18 kg (Overall Kit)
