Item Type
1 x COB LED Light Panel
Included Storage Case
None
Photometrics
5600K:
3086 fc / 33,205 Lux at 3.3' / 1 m
342 fc / 3679 Lux at 9.8' / 3 m
86 fc / 925 Lux at 19.6' / 6 m
30 fc / 322 Lux at 32.8' / 10 m
*Standardized Measurement Supplied by the Manufacturer
3200K:
2916 fc / 31,376 Lux at 3.3' / 1 m
324 fc / 3486 Lux at 9.8' / 3 m
80 fc / 860 Lux at 19.6' / 6 m
30 fc / 322 Lux at 32.8' / 10 m
*Standardized Measurement Supplied by the Manufacturer
5600K:
2526 fc / 27,179 Lux at 3.3' / 1 m (with Filter)
280 fc / 3012 Lux at 9.8' / 3 m (with Filter)
70 fc / 753 Lux at 19.6' / 6 m (with Filter)
26 fc / 279 Lux at 32.8' / 10 m (with Filter)
*Standardized Measurement Supplied by the Manufacturer
3200K:
2396 fc / 25,780 Lux at 3.3' / 1 m (with Filter)
266 fc / 2862 Lux at 9.8' / 3 m (with Filter)
66 fc / 710 Lux at 19.6' / 6 m (with Filter)
24 fc / 258 Lux at 32.8' / 10 m (with Filter)
*Standardized Measurement Supplied by the Manufacturer
Show More
Color Temperature
1500 to 20,000K
Color Modes
RGB, Daylight, Tungsten
Color Accuracy Standard
CRI 99
TLCI 93
Dimming
Yes, Built-In Dimmer
0 to 100% (Continuous)
Beam Angle
120° Unmodified
106° with Included Diffuser
Front Accessory Mount
Proprietary
Wireless Remote Control Type
Art-Net
Bluetooth 5.0
Wireless CRMX
Wireless DMX (G3 / G4 / G4S / G5)
Show More
Power Source
AC Power (Cable Included) *Requires Power Supply/Controller (Included)
Battery (Not Included)
AC Input Power
100 to 240 VAC, 50 / 60 Hz
DC Input Power
48 VDC
Power Consumption
1600 W
Fixture Mounting
1 x 1.1" / 28 mm Unthreaded Hole (Via Yoke Mount)
Proprietary
Light Fixture
Item Type
1 x COB LED Light Panel
Included Filters
Diffusion
Included Storage Case
None
Lumens
103,618 (at 5600K)
95,506 (at 3200K)
Photometrics
5600K:
3086 fc / 33,205 Lux at 3.3' / 1 m
342 fc / 3679 Lux at 9.8' / 3 m
86 fc / 925 Lux at 19.6' / 6 m
30 fc / 322 Lux at 32.8' / 10 m
*Standardized Measurement Supplied by the Manufacturer
3200K:
2916 fc / 31,376 Lux at 3.3' / 1 m
324 fc / 3486 Lux at 9.8' / 3 m
80 fc / 860 Lux at 19.6' / 6 m
30 fc / 322 Lux at 32.8' / 10 m
*Standardized Measurement Supplied by the Manufacturer
5600K:
2526 fc / 27,179 Lux at 3.3' / 1 m (with Filter)
280 fc / 3012 Lux at 9.8' / 3 m (with Filter)
70 fc / 753 Lux at 19.6' / 6 m (with Filter)
26 fc / 279 Lux at 32.8' / 10 m (with Filter)
*Standardized Measurement Supplied by the Manufacturer
3200K:
2396 fc / 25,780 Lux at 3.3' / 1 m (with Filter)
266 fc / 2862 Lux at 9.8' / 3 m (with Filter)
66 fc / 710 Lux at 19.6' / 6 m (with Filter)
24 fc / 258 Lux at 32.8' / 10 m (with Filter)
*Standardized Measurement Supplied by the Manufacturer
Color Temperature
1500 to 20,000K
Color Modes
RGB, Daylight, Tungsten
Color Accuracy Standard
CRI 99
TLCI 93
Cooling System
None
Dimming
Yes, Built-In Dimmer
0 to 100% (Continuous)
Expected Lamp Life
50,000 Hours
Beam Angle
120° Unmodified
106° with Included Diffuser
Built-In Flash
No
Umbrella Mount
No
Front Accessory Mount
Proprietary
Connectivity
Wireless Remote Control Type
Art-Net
Bluetooth 5.0
Wireless CRMX
Wireless DMX (G3 / G4 / G4S / G5)
Mobile App Compatible
Yes: Android & iOS
App Name: ARRI LiCo
*As of September, 2023: Check with manufacturer for the most up-to-date compatibility
Power & I/O
Power Source
AC Power (Cable Included) *Requires Power Supply/Controller (Included)
Battery (Not Included)
Inputs/Outputs
Light Fixture
2 x XLR 5-Pin DMX Input
2 x XLR 5-Pin DMX Output
4 x etherCON/RJ45 DMX/Network Input/Output
2 x USB-C Remote/Service Input
2 x XLR 3-Pin Battery Input (48 VDC)
To Light Fixture: 2 x powerCON TRUE1 TOP Power Input
2 x Unspecified Remote Input
AC Input Power
100 to 240 VAC, 50 / 60 Hz
DC Input Power
48 VDC
Inline Switch
No
Power Pass-Thru
Yes
Power Consumption
1600 W
Power Supply
Built-In
Mounting
Yoke Type
Manually-Operated Yoke
Fixture Mounting
1 x 1.1" / 28 mm Unthreaded Hole (Via Yoke Mount)
Proprietary
Environmental
Environmental Protection
Advertised as Dust Resistant/Moisture Resistant/Weather Resistant
*Manufacturer Testing: IP66
General
Display
Yes
Certifications
CE, CB, ENEC, cNRTLus, FCC, UKCA, ICES, PSE, KC
Dimensions
29.1 x 13.3 x 6.1" / 73.8 x 33.9 x 15.4 cm (Fixture Panel without Yoke)
Weight
66.1 lb / 30 kg (Fixture without Yoke)
83.8 lb / 38 kg (Overall Kit)
