Item Type
1 x COB LED Light Panel
Included Storage Case
None
Photometrics
5600K:
4629 fc / 49,808 Lux at 3.3' / 1 m
513 fc / 5519 Lux at 9.8' / 3 m
129 fc / 1388 Lux at 19.6' / 6 m
45 fc / 484 Lux at 32.8' / 10 m
*Standardized Measurement Supplied by the Manufacturer
3200K:
4374 fc / 47,064 Lux at 3.3' / 1 m
486 fc / 5229 Lux at 9.8' / 3 m
120 fc / 1291 Lux at 19.6' / 6 m
45 fc / 484 Lux at 32.8' / 10 m
*Standardized Measurement Supplied by the Manufacturer
5600K:
3789 fc / 40,769 Lux at 3.3' / 1 m (with Filter)
420 fc / 4519 Lux at 9.8' / 3 m (with Filter)
105 fc / 1129 Lux at 19.6' / 6 m (with Filter)
39 fc / 419 Lux at 32.8' / 10 m (with Filter)
*Standardized Measurement Supplied by the Manufacturer
3200K:
3594 fc / 38,671 Lux at 3.3' / 1 m (with Filter)
399 fc / 4293 Lux at 9.8' / 3 m (with Filter)
99 fc / 1065 Lux at 19.6' / 6 m (with Filter)
36 fc / 387 Lux at 32.8' / 10 m (with Filter)
*Standardized Measurement Supplied by the Manufacturer
Show More
Color Temperature
1500 to 20,000K
Color Modes
RGB, Daylight, Tungsten
Color Accuracy Standard
CRI 99
TLCI 93
Dimming
Yes, Built-In Dimmer
0 to 100% (Continuous)
Beam Angle
120° Unmodified
106° with Included Diffuser
Front Accessory Mount
Proprietary
Wireless Remote Control Type
Art-Net
Bluetooth 5.0
Wireless CRMX
Wireless DMX (G3 / G4 / G4S / G5)
Show More
Power Source
AC Power (Cable Included) *Requires Power Supply/Controller (Included)
Battery (Not Included)
AC Input Power
100 to 240 VAC, 50 / 60 Hz
DC Input Power
48 VDC
Power Consumption
2400 W
Fixture Mounting
1 x 1.1" / 28 mm Unthreaded Hole (Via Yoke Mount)
Proprietary
Light Fixture
Item Type
1 x COB LED Light Panel
Included Filters
Diffusion
Included Storage Case
None
Lumens
155,427 (at 5600K)
144,759 (at 3200K)
Photometrics
5600K:
4629 fc / 49,808 Lux at 3.3' / 1 m
513 fc / 5519 Lux at 9.8' / 3 m
129 fc / 1388 Lux at 19.6' / 6 m
45 fc / 484 Lux at 32.8' / 10 m
*Standardized Measurement Supplied by the Manufacturer
3200K:
4374 fc / 47,064 Lux at 3.3' / 1 m
486 fc / 5229 Lux at 9.8' / 3 m
120 fc / 1291 Lux at 19.6' / 6 m
45 fc / 484 Lux at 32.8' / 10 m
*Standardized Measurement Supplied by the Manufacturer
5600K:
3789 fc / 40,769 Lux at 3.3' / 1 m (with Filter)
420 fc / 4519 Lux at 9.8' / 3 m (with Filter)
105 fc / 1129 Lux at 19.6' / 6 m (with Filter)
39 fc / 419 Lux at 32.8' / 10 m (with Filter)
*Standardized Measurement Supplied by the Manufacturer
3200K:
3594 fc / 38,671 Lux at 3.3' / 1 m (with Filter)
399 fc / 4293 Lux at 9.8' / 3 m (with Filter)
99 fc / 1065 Lux at 19.6' / 6 m (with Filter)
36 fc / 387 Lux at 32.8' / 10 m (with Filter)
*Standardized Measurement Supplied by the Manufacturer
Color Temperature
1500 to 20,000K
Color Modes
RGB, Daylight, Tungsten
Color Accuracy Standard
CRI 99
TLCI 93
Cooling System
Fan/Passive Combo
Dimming
Yes, Built-In Dimmer
0 to 100% (Continuous)
Expected Lamp Life
50,000 Hours
Beam Angle
120° Unmodified
106° with Included Diffuser
Built-In Flash
No
Umbrella Mount
No
Front Accessory Mount
Proprietary
Connectivity
Wireless Remote Control Type
Art-Net
Bluetooth 5.0
Wireless CRMX
Wireless DMX (G3 / G4 / G4S / G5)
Mobile App Compatible
Yes: Android & iOS
App Name: ARRI LiCo
*As of September, 2023: Check with manufacturer for the most up-to-date compatibility
Power & I/O
Power Source
AC Power (Cable Included) *Requires Power Supply/Controller (Included)
Battery (Not Included)
Inputs/Outputs
Light Fixture
3 x XLR 5-Pin DMX Input
3 x XLR 5-Pin DMX Output
6 x etherCON/RJ45 DMX/Network Input/Output
3 x USB-C Remote/Service Input
3 x XLR 3-Pin Battery Input (48 VDC)
To Light Fixture: 3 x powerCON TRUE1 TOP Power Input
3 x Unspecified Remote Input
AC Input Power
100 to 240 VAC, 50 / 60 Hz
DC Input Power
48 VDC
Inline Switch
No
Power Pass-Thru
Yes
Power Consumption
2400 W
Mounting
Yoke Type
Manually-Operated Yoke
Fixture Mounting
1 x 1.1" / 28 mm Unthreaded Hole (Via Yoke Mount)
Proprietary
Environmental
Environmental Protection
Advertised as Dust Resistant/Moisture Resistant/Weather Resistant
*Manufacturer Testing: IP66
General
Display
None
Certifications
CE, CB, ENEC, cNRTLus, FCC, UKCA, ICES, PSE, KC
Dimensions
29.1 x 13.3 x 6.1" / 73.8 x 33.9 x 15.4 cm (Fixture Panel without Yoke)
Weight
52.9 lb / 24 kg (Fixture without Yoke)
119 lb / 54 kg (Overall Kit)
