Bonding
Support for up to 4 additional Node Modems using 5-pin connectors and external power
Supported Modems +
Supported Modems
Node II
Node II CBRS
Node 5G
Power Input
Requires external power from standard PTAP adapter, Gold, V-Lock Battery Plates NOTE: 26V IS NOT SUPPORTED.
Recommended Battery: Anton Bauer Batteries
Prism Mobile 5G
Video Inputs
1 x SD/HD/3G/6G/12G-SDI (75 Ω BNC)
1 x HDMI 2.0 Type-A
Hdr Support
Yes (2020-PQ, 2020-HLG, P3D65-PQ)
Video Outputs
1 x SD/HD/3G/6G/12G-SDI (75 Ω BNC)
Supported Modes
Single Encode, Bi-directional Encode/Decode (additional license)
Bonding
Teradek Bonding Protocol, Teradek Reliable Transport (TRT)
Supported Resolutions +
Supported Resolutions
4K DCI p23.98/24/25/29.97/30/50/59.94/60
4K UHD p23.98/24/25/29.97/30/50/59.94/60
1080p 23.98/24/25/29.97/30/50/59.94/60
1080i 50/59.94/60
1080PsF 23/24/25/29/30
720p 50/59.94/60
576i 480i
Video Compression
ISO MPEG-4 Part 10: Advanced Video Coding (AVC)/ITU H.264
AVC: Baseline, Main, High
ISO MPEG-H Part 2: High Efficiency Video Coding (HEVC)/ITU H.265
HEVC: Main
Supported Video Bitrate
250 kbps to 85 Mbps
Video Format Conversion Support
Built in video scaler and deinterlacer
Number Of Encoder Streams
Up to one 4KDCI p60 4:2:2 10bit
Color Correction
CDL/1024 1D LUT (supports 10-bit color)
33x33x33 3D LUT (supports 10-bit color)
Network Protocols
TCP/IP, UDP, HTTP, DHCP, NTP, TLS, IGMP
Supported Video Transport Protocols
Teradek Reliable Transport (TRT)
Secure Reliable Transport (SRT)
RTMP/RTMPS
MPEG-TS, DASH (UDP, TCP, TCP Server, Multicast)
RTSP/RTP
RIST
HLS Client
Integrated CDNs (YouTube, Facebook, Vimeo),
WHIP
Remote Control
Teradek Core Cloud, Private SDK
Audio Processing +
Audio Compression
AAC-LC
Audio Bitrate
32kbps to 512kbps
Audio Input
Embedded over SDI
3.5mm Stereo Line Level Analog or Microphone in, adjustable gain
Outputs +
Audio Output
3.5mm Stereo Headphone output
Analog 3.5mm Line Level, USB-A Headset or Audio Interface (< 1.5A)
Dimensions
5.9"W x 3.9"D x 1.3"H [162 x 92 x 35mm]
Weight
23.4oz [664g] without plates; 30.5oz (864g) with plates
Construction
Milled Aluminum
Mountability
Camera-back, Gold, Gold 26V and V-Lock mounts. Can be mounted with 1/4" 20 mounting hole
Configuration Interfaces
Core Cloud for remote device management
Feature-rich Web UI for local device management
Intuitive iOS configuration app
OLED Status Display w/ Nav control buttons
Cellular
2x Internal Node 5G - SW Modems (CBRS supported)
Recording Storage
SD Card - Full size, USB Drive, NFS
Cloud Services
Native Sync with the following:
Core Cloud
Frame.io
Sony Ci
Sony C3 Portal
Avid
PIX
Moxion
Usb Interface Functionality
1 x Powered LEMO with Node Modem support
1 x Powered USB-A with Node and external storage support
Network
Ethernet
2 x 10/100/1000 BASE-T Gigabit Ethernet (RJ45)
Wireless
WiFi: 2.4/5GHz 802.11 a/b/g/n/ac/ax MIMO - BLE for Network Configuration
Power Input
2 Pin Circular Locking Connector
Nominal Power Consumption
20W Nominal, 36W Max
Auxilary Power Input
6-28V DC
